HSP-C7A-B2-500
Hyperspan Core™ Cat7A S/FTP LSZH B2ca-s1,d1,a1 500 m Box Blue
Hyperspan Core™ Cat7A solid copper bulk cable. Cable type S/FTP, 23 AWG Class 1 solid conductor, LSZH outer sheath (Blue). Declared reaction-to-fire B2ca-s1,d1,a1 under EN 13501-6 / EN 50575. Supplied as 500 m Box. Confirm certified documentation with Hyperspan Technical Support.
Key features
- Cat7A solid copper bulk cable
- S/FTP
- 23 AWG solid conductor
- LSZH, Blue
- Reaction to fire B2ca-s1,d1,a1
- Supplied as 500 m Box
- Category
- Cat7A
- Cable type
- S/FTP
- Overall screening
- Braided + foil
- Conductor material
- Solid bare copper
- Conductor surface
- Bare
- AWG size
- 23
- Conductor category
- Class 1 = solid
- Total number of cores
- 8
- Outer sheath material
- LSZH
- Outer sheath colour
- Blue
- Reaction to fire (EN 13501-6)
- B2ca-s1,d1,a1
- CPR euroclass
- B2ca
- Smoke production
- s1
- Flaming droplets / particles
- d1
- Acidity / corrosivity
- a1
- Packaging
- 500 m Box
- Application
- Commercial Buildings
- Warranty
- 25-Year System Warranty
Fire / CPR classification
B2ca-s1,d1,a1
Smoke s1 · Droplets d1 · Acidity a1
Saved to your BOM on this device. Partner login to keep it as your order basket and export a PDF.
Documents are generated in the same branded PDF style as other Hyperspan downloads. Confirm certified DoP / CoC revisions with Hyperspan Technical Support for live projects and regulatory submission.
