Technical Specifications
Extended-reach Cat6-class copper infrastructure
Hyperspan™ Cat6 is a next-generation Cat6-class copper cable engineered to support extended Ethernet distances beyond the traditional 90–100 metre limit, while maintaining stable data and power delivery without active electronics.
Designed for distance-challenged deployments such as CCTV, Wi-Fi, access control, and edge devices — where conventional Cat6 often forces extra cabinets, intermediate switches, PoE extenders, local power, and cooling infrastructure.
Design philosophy
- Maximise usable Ethernet reach over passive copper
- Maintain stable signal integrity and PoE delivery over extended distances
- Simplify network topology and structured cabling design
- Reduce active hardware, power consumption, and points of failure
- Preserve familiar Cat6 installation and termination practices
Intended use
Hyperspan is designed for applications where extended cable runs are required. Actual performance depends on channel design, device capability, PoE load, and installation quality.
Technical positioning & compliance notice
Hyperspan is a Cat6-class copper solution designed to exceed typical real-world Cat6 performance expectations for extended-reach applications. As with any extended-reach Ethernet deployment, careful consideration must be given to channel length, data rate, PoE power class, and device tolerance.
Full technical specifications and test data are provided to support proper network design and validation.
Supported distances & data rates
Hyperspan™ is engineered to support extended passive copper Ethernet runs beyond typical Cat6 deployment limits. Performance depends on data rate, PoE load, device capability, and installation quality.
| Data rate | Maximum channel length* | PoE support | Typical applications |
|---|---|---|---|
| 2.5 Gbps | Up to ~200 metres | PoE / PoE+ / PoE++ | CCTV, Wi-Fi APs, access control, edge devices |
| 1000 Mbps | Up to ~220 metres | PoE / PoE+ / PoE++ | Cameras, controllers, IoT |
| 10 Mbps | Up to ~259 metres | PoE / PoE+ / PoE++ | Long-reach control, telemetry, monitoring |
* Maximum channel length includes horizontal cable and patching. Actual performance may vary based on environmental conditions, connector quality, and device tolerance.
Design guidance
- Optimised for extended-reach, point-to-device connections
- Best results are achieved with direct home-run topology
- Avoid unnecessary patching or intermediate cross-connects on long runs
- For distances approaching maximum values, validate device compatibility during commissioning
PoE capabilities
Hyperspan™ is designed to support extended-reach Power over Ethernet (PoE) delivery without active mid-span electronics.
Supported PoE standards
- IEEE 802.3af (PoE)
- IEEE 802.3at (PoE+)
- IEEE 802.3bt (PoE++)
This enables reliable power and data delivery to devices located significantly further from the network core than traditional Cat6 installations allow.
| PoE standard | Power class | Typical reach* | Example devices |
|---|---|---|---|
| PoE (af) | Up to 15.4W | Up to ~220m | Basic IP cameras, sensors |
| PoE+ (at) | Up to 30W | Up to ~200m | PTZ cameras, access controllers |
| PoE++ (bt) | Up to 60–90W | Up to ~200m | Wi-Fi 6/6E APs, high-power cameras |
* Reach varies depending on cable length, conductor resistance, power draw, and environmental conditions.
Key PoE benefits
- Eliminates the need for local power supplies
- Reduces the number of cabinets and power outlets
- Simplifies long-distance edge device deployment
- Supports cleaner, more reliable network designs
PoE design considerations
- Higher power loads reduce maximum achievable distance
- Ensure connected devices support negotiated PoE class
- Use quality connectors and termination to minimise resistance
- Validate high-power deployments during commissioning
Product Specification Downloads
Access the latest official Hyperspan product specification sheets below. These PDFs contain detailed electrical performance, mechanical characteristics, and installation guidance for each Hyperspan variant.
External Pre-Term Reel 250 — Combined Spec Sheet
Download Technical Spec Sheet (PDF) →
Internal B2ca — Combined Spec Sheet
Download Technical Spec Sheet (PDF) →
External Pre-Term Reel — Combined Spec Sheet
Download Technical Spec Sheet (PDF) →
Each PDF opens in a new tab. Contact us if you need combined specification packages or printable versions.
Technical disclaimer
Hyperspan™ extended-reach performance figures are based on controlled testing and real-world deployment scenarios. Actual results depend on network design, device tolerance, PoE load, and installation quality. Hyperspan is intended for extended-reach applications where standard Cat6 designs would normally require additional active infrastructure.
