HSP-RACK-WL-9U-550
Wall-Mount Cabinet 9U 550 mm Deep
HSP-RACK-WL-9U-550 is a 9U Hyperspan Rack wall-mount cabinet. The footprint is 600 × 550 mm. The front door locks. 19-inch EIA-310 rails, numbered in U, carry the equipment. It is supplied flat-packed as a kit to hang and fit on site. Typical use: Branch / retail comms. Specify it with Power PDUs, Rack panels and Hyperband fibre as a Hyper House bill of materials.
Key features
- 9U of 19-inch mounting
- 600 × 550 mm footprint
- Numbered EIA-310 rails
- Lockable front door
- Black powder-coated steel
- Supplied flat-packed to hang and fit
Technical data
- Product code
- HSP-RACK-WL-9U-550
- Cabinet
- Wall-mount
- Rack units
- 9U
- Footprint
- 600 × 550 mm
- Width
- 600 mm
- Depth
- 550 mm
- Mounting
- 19-inch EIA-310
- Rails
- One pair, numbered in U
- Front door
- Lockable steel
- Material
- Steel
- Finish
- Black powder coat
- Supply
- Flat-packed, hang and fit
- Application
- Branch / retail comms
- Warranty
- Product warranty; 25-Year System Warranty applies to qualifying registered Hyperspan channels
Saved to your BOM on this device. Partner login to keep it as your order basket and export a PDF.
Documents are generated in the same branded PDF style as other Hyperspan downloads. Confirm certified DoP / CoC revisions with Hyperspan Technical Support for live projects and regulatory submission.
Flat-pack build
How this cabinet goes together
It is supplied flat-packed as a kit to hang and fit on site. The numbered drawing matches the parts in the pack and the assembly manual.
Parts
- 1Rear mounting panelFixes to the wall. Mark the holes from this panel.
- 2Enclosure bodyThe cabinet carcass.
- 319-inch railsEIA-310 pair inside the body.
- 4Front doorLockable steel leaf.
Build sequence
- 1.Unpack and check the rear panel (1), body (2), rails (3) and door (4).
- 2.Assemble the body to the rear panel on a bench when they arrive separate.
- 3.Mark the wall from the rear panel, drill, and fit fixings suited to that wall.
- 4.Lift the cabinet onto the wall with two people and check that it is level.
- 5.Fit the 19-inch rails (3).
- 6.Hang and lock the front door (4).
- 7.Bond the earth before the cabinet is energised, then load the equipment.
Before you start
- Use two people to lift the cabinet onto the wall.
- Wear gloves. Flat-pack steel edges are sharp.
- Confirm the wall construction and use fixings rated for the finished weight.
- Leave the frame fixings finger-tight until the diagonals match, then tighten.
- Do not load equipment until the rails are fitted and the cabinet is in its final position.
- A published static load is a standing load. Do not roll a loaded cabinet.
- Bond the frame to earth before any PDU or active equipment is energised. The earth bonding kit is a separate accessory.
- Baying kits, plinths, castors, fan trays, blanking panels and M6 cage nuts are ordered separately.
